Magnetic Compass Acceleration & Turning Errors
CASA Ref: CASR Part 61 MOS Schedule 3 CNAV 1.2 · FAA Ref: FAA-S-ACS-6C Area I Task H (Flight Instruments)
Scenario & Physics Summary
ANDS (Accelerate North, Decelerated South) and UNOS (Undershoot North, Overshoot South) magnetic dip errors explained.
Interactive 3D Visual Plates & Scenario Media
Plate 1: Magnetic Compass Acceleration & Turning Errors
Plate 2: Magnetic Compass Acceleration & Turning Errors
Plate 3: Magnetic Compass Acceleration & Turning Errors
Plate 4: Magnetic Compass Acceleration & Turning Errors
Aerodynamic & Operational Physics
- Earth magnetic flux lines dip downward near the poles. The magnetic compass card center of gravity is offset to counter dip.
- Acceleration Error (East/West headings): Acceleration causes CG inertia to lag, rotating card toward North (ANDS). Deceleration rotates card toward South.
- Turning Error (Turning North/South): Turning FROM North causes lag (Undershoot North). Turning FROM South causes lead (Overshoot South).
CASA & FAA Exam Gotcha Alert
CASA / FAA Exam Trap: Acceleration error occurs ONLY on East and West headings. Turning error is maximum when turning through North or South.
Frequently Asked Questions & Exam Explanations
What does the ANDS mnemonic stand for?
Accelerate North, Decelerate South on East or West magnetic headings in the Northern Hemisphere (reversed in Southern Hemisphere for dip direction).
Master Magnetic Compass Acceleration & Turning Errors in the Simulator
Drill targeted CASA and FAA exam questions with step-by-step mathematical decoders and regulatory clause links.
